AUTO RELAY, 301-1C-C-R1-U01-12VDC, SPDT, 12VDC 35A

All pictures are for illustrative purposes only.

PID# 160784

11,50 CA$
Free shipping: On orders over $120 within BC

2 In Stock

Order now, processed next business day

Quantité

Request a large quantity quote

Description

Coil Voltage: 12 VDC

Relay Contact Form: 1 Form C (SPDT-NO, NC)

Coil Resistance: 123 Ohms

Mounting Style: Socket

Series: 301

Length: 25 mm

Width: 22.5 mm

Height: 15 mm

Contact Form: SPDT (1 Form C)

Contact Termination: Quick Connect

Power Consumption: 1.2 W

Unit Weight: 20 g
