RELAY, SCHNEIDER ICE CUBE, 781XAXRM4L-12D, SPDT, 12VDC, 15A

All pictures are for illustrative purposes only.

PID# 160167

26,00 CA$
Free shipping: On orders over $120 within BC
Quantité

Request a large quantity quote

Description

Datasheet

Features:

  • Socket, panel, and DIN mounting options
  • Multiple features and contact configurations available
  • Optional protection, mounting, and identification accessories
  • Ideal choice for direct replacement in MRO applications (maintenance, repair, and operations)
  • UL Class I Division 2 models for hazardous locations
  • Contact Configuration: SPDT
  • Coil Voltage: 12VDC
  • Contact Current: 15A
  • Product Range: 781 Series
  • Coil Type: -
  • Contact Voltage VAC: 277VAC
  • Relay Terminals: Quick Connect
  • Relay Type: Power - General Purpose
  • Contact Voltage VDC: 28VDC
  • Contact Material: Silver Alloy
  • Coil Resistance: 188ohm
  • Approvals & Standards: -
