POWER RELAY, TE, RZ03-1C4-D024, 24VDC, 16A SPDT

All pictures are for illustrative purposes only.

PID# 161178

6,50 CA$
Free shipping: On orders over $120 within BC
Quantité

Request a large quantity quote

Description

Coil Voltage: 24VDC

Contact Form: SPDT (1 Form C)

Contact Rating (Current): 16 A

Switching Voltage: 400VAC - Max

Load - Max Switching: 6400VA

Coil Current: 16.7 mA

Coil Type: Non Latching

Termination Style: PC Pin

Coil Insulation: Class F

Must Operate Voltage: 16.8 VDC

Must Release Voltage: 2.4 VDC

Operate Time: 8 ms

Release Time: 6 ms

Operating Temperature: -40°C ~ 85°C

Contact Material: Silver Nickel (AgNi)

Approval Agency: CQC, cURus, VDE

Specifications

4 Produits

Features

Coil Voltage 24VDC
Contact Configuration SPDT
