TOGGLE SWITCH, DPDT, ON-ON, 20A, SCREW ON T702 BW

All pictures are for illustrative purposes only.

PID# 349

4,95 CA$ EACH
Free shipping: On orders over $120 within BC
Variants:
ON-OFF
ON-ON
ON-OFF-ON
ON-OFF-(ON)
(ON)-OFF-(ON)
Quantité

Request a large quantity quote

Description

TOGGLE SWITCH,DPDT,ON-ON,20A,SCREW ON T702 BW

The authentication institutions

CE

Assembly method

Casing assembly

Extreme number

2 very DPDT

Installing hole size

diameter:12.5mm

ratings

10A 250VAC 15A 125VAC 1/2HP

125-25

Mechanical life

More than 50.000 cycles

Dielectric strength

1,000 V RMS (min)

Electrical life

More than 10,000 cycles

Insulation resistance

100 MΩ(min)

Environment temperature

- 25 degrees ~ 80 degrees

Basal material

Poly propylene materials

humidity

850℃below

Withstand voltage

2000V, 50/60Hz lasts 1 min

vibration

10 to 55Hz, 1.5 mm double amplitude

Specifications

39 Produits

Features

Cutout Diameter 12mm
