TOGGLE SWITCH, DPDT, ON-OFF-(ON), 15A, SCREW LUG

All pictures are for illustrative purposes only.

PID# 3234

6,05 CA$ EACH
Free shipping: On orders over $120 within BC
Variants:
ON-OFF
ON-ON
ON-OFF-ON
ON-OFF-(ON)
(ON)-OFF-(ON)
Quantité

Request a large quantity quote

Description

Heavy duty toggle switch. ON - OFF - TEMPORARY ON. 10A 250VAC 15A 125VAC 1/2HP

The authentication institutions
CE

Assembly method

Casing assembly

Extreme number
2 very DPDT

Installing hole size

diameter:12.5mm

ratings
10A 250VAC 15A 125VAC 1/2HP
125-25

Mechanical life

More than 50.000 cycles

Dielectric strength
1,000 V RMS (min)
Electrical life

More than 10,000 cycles

Insulation resistance
100 MΩ(min)

Environment temperature

- 25 degrees ~ 80 degrees

Basal material

Poly propylene materials

humidity

850℃ below

Withstand voltage

2000V, 50/60Hz lasts 1 min

vibration

10 to 55Hz, 1.5 mm double amplitude



Specifications

6 Produits

Features

Cutout Diameter 12mm
