LATCHING RELAY, SPST-NO, 12VDC 16A, FORM-A RTT3TA12

All pictures are for illustrative purposes only.

PID# 32785

15,00 CA$
Free shipping: On orders over $120 within BC

2 In Stock

Order now, processed by tomorrow

Quantité

Request a large quantity quote

Description

SpecificationValue
Relay Construction Latching, Single Coil
Contact Form SPST-NO
Coil Voltage 12 VDC
Coil Resistance 360 Ohm
Contact Current 16 A
Contact Voltage 400 VAC
Pins 6
Length 29.8 mm
Width 13 mm
Height 23 mm
Family RT1
Maximum Pick-Up Voltage 8.4 VDC
Minimum Dropout Voltage n/a
Operate Time 10 ms
Maximum Operating Temperature 85°C
Minimum Operating Temperature -10°C

Specifications

2 Produits

Features

Coil Voltage 12VDC
Contact Configuration SPST
