GROVE OLED DISPLAY 1.12IN V2

All pictures are for illustrative purposes only.

PID# 15411

20,00 CA$
Rupture de stock
Quantité

Request a large quantity quote

Description

Description
Grove - OLED 1.12'' is a 16 color grayscale 96×96 dot matrix OLED display module with Grove compatible 4pin I2C interface.Grove - OLED 1.12" is constructed with 96 x 96 dot matrix OLED module ([ LY120])and SSD1327 driver IC. The characteristics of this display module are high brightness, self-emission, high contrast ratio, slim / thin outline, wide viewing angle, wide temperature range, and low power consumption.

KEY FEATURES

    • - Dot Matrix: 96 x 96 Pixels
    • - Color: Grayscale Display (16 Gray shades)
    • - Supports both Normal and Inverse Color Display
    • - Supports Continuous Horizontal Scrolling
    • - Grove compatible 4pin I2C connector
    • - Works with both 5V and 3.3V logic MCUs
    • - Interface: I2C
    • - Wide range of operating temperature: -40 °C ~ 70 °C

APPLICATION IDEAS

    • - Graphic display adapter for Seeeduino and Arduino using Grove stem board
    • - Display adapter for any 5V or 3.3V MCU which supports I2C interface
    • - Can be used with mbed microcontroller
